The BABY COMPACT is ideally suited for the planting of balled root seedlings conical or pyramidal in shape. (Even in small sizes with reduced amount of leaves and roots. E.g. Radicchio, lettuce etc.)
The BABY COMPACT is fitted with a 'High range paralellogram system' that allows for exceptional contour hugging capabilities and by means of adjustable springs, one can increase or decrease the pressure exerted by the closing wheels. The Planting units are driven by a set of Master Land wheels through a Hex shaft.
Key points:
* Rotary cup type Ideally suited for planting of close-line salads
* Independent Floating unit with Paralellogram linkage for exceptional contour hugging capabilities
* Transplant units driven by a set of master Land wheels through a Hexagon shaft
* Extreme compact planter - Suited for tight work spaces, high slopes and terraces
* Production 3000/4500 plants per hour per row
General Characteristics
- Transplants Conical & Pyramid shaped clods between Ø20-30mm
even in small sizes with reduced amount of leaves like;
Radicchio, lettuce, etc.
- Baby compact ideally suited for small farms and tight spaces
- Distribution system; Horizontal with continuous rotation (6 Cup)
- Inter-row spacing; Minimum 28cm
- Inter-plant spacing, from 14 to 50cm (Optional 31 to 82cm)
- Operator production; 3000 / 4500 plants per hour per row
- Independent floating paralellogram transplant units
- Packing wheels; In Flex rubber (Ø410mm)
- Range of optional equipment available
